ABRACON IS

ISO9001-2015

CERTIFIED

Multi-layer Chip Diplexer

ADID-R-0004

1.0 x 0.5 x 0.4 mm

RoHS Compliant

Request Samples

Check Inventory

5101 Hidden Creek Ln Spicewood TX 78669

Phone: 512-371-6159 | Fax: 512-351-8858

REVISED: 02-19-24

For terms and conditions of sales, please visit:

www.abracon.com

Parameters

Specification

Unit

Notes

Center Frequency

2400-2500

5150-7125

MHz

Insertion Loss (Max)

0.50

0.90

@25℃

Insertion Loss (Max)

0.65

1.10

40~85℃

Absolute Attenuation

15.0 dB min. @4800~6000 MHz

15.0 dB min. @5150-7125 MHz

20.0 dB min. @7200-7500 MHz

24.0 dB min. @ 500~2400 MHz

26.0 dB min. @ 2400~2500 MHz

19.0 dB min. @ 2500~2690 MHz

9.0 dB min. @ 10300~11900 MHz

13.5 dB min. @ 11900~12490 MHz

11.5 dB min. @ 12490~14250 MHz

8.0 dB min. @ 15510~21375 MHz

Isolation (Min)

16.5

Return Loss (Min)

@25℃

Power Capacity

2.0

Parameters

Specifications

Filter Dimension

1.0 x 0.5 x 0.4 mm

Mounting Type

SMD Mount

Parameters

Specifications

Operating Temperature

-40ºC ~ +85ºC

Storage Temperature

-10ºC ~ +45ºC

Humidity

70% R.H.

RoHS Compliant

Yes

Electrical Specifications

Environmental Specifications

Mechanical Specifications
