Wi-Fi 6/6E/7 LTCC RF Diplexer

ADID-R-0012

1.6 x 0.8 x 0.65 mm

RoHS Compliant

Request Samples

Check Inventory

Parameters

Specification

Units

Notes

Passband

2400-2500

5150-7150

MHz

Insertion Loss

0.5

1.0

@25ºC

0.7

1.3

@-40ºC ~ +85ºC

VSWR

< 2.0

Attenuation (min.)

4800 ~ 5000 MHz

7200 ~ 7500 MHz

2400 ~ 2500 MHz

10300 ~ 14300 MHz

15300 ~ 21450 MHz

Isolation (min.)

2400 ~ 2500 MHz

4800 ~ 5000 MHz

5000 ~ 6000 MHz

6000 ~ 7150 MHz

Power Capacity

Parameters

Specifications

Filter Dimension

1.6 x 0.8 x 0.65 mm

Mounting Type

Surface Mount

Parameters

Specifications

Operating Temperature

-40ºC ~ +85ºC

Storage Temperature

-10ºC ~ +40ºC (70% R.H. max)

Humidity

90% - 95% R.H.

Electrical Specifications

Environmental Specifications

Mechanical Specifications
