Features

•

Low profile design – 1.1mm package typical height

•

Wettable flanks for automatic visual inspection

•

Very low conduction losses

•

High forward surge current capability

•

ECOPACK2 compliant

Applications

•

DC/DC converter

•

Stand by power

•

Oring

•

Polarity protection

Description

This 2 x 5 A, 40 V Schottky diode is suitable for power supply, especially for lighting

power, as well as auxiliary power in server or telecom SMPS.

Packaged in PSMC (TO-277A), this STPS10L40CSF, dual diode device provides a

high level of efficiency in a compact and flat package is ideal for oring function in

server for instance.

Product status link

STPS10L40CSF

Product summary

IF(AV)

2 x 5 A

VRRM

40 V

Tj (max.)

150 °C

VF (typ.)

0.370 V

40 V, 2 x 5 A low forward voltage power Schottky rectifier

STPS10L40CSF

Datasheet

DS13739 - Rev 1 - May 2021
