www.ti.com

PACKAGE OUTLINE

C

12X 0.65

2X

3.9

14X

0.38

0.22

8.2

7.4

TYP

SEATING

PLANE

0.05 MIN

0.25

GAGE PLANE

0 -8

2 MAX

0.25

0.09

B

5.6

5.0

NOTE 4

A

6.5

5.9

NOTE 3

0.95

0.55

SSOP - 2 mm max height

DB0014A

SMALL OUTLINE PACKAGE

4220762/A 05/2024

1

7

8

14

0.15

C A B

PIN 1 INDEX AREA

SEE DETAIL A

0.1 C

NOTES:

1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing

per ASME Y14.5M.

2. This drawing is subject to change without notice.

3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions, or gate burrs shall not

exceed 0.15 mm per side.

4. Reference JEDEC registration MO-150.

A 15

DETAIL A

TYPICAL

SCALE 2.000
