DS017-7

Mar ‘03

©2003 REG No 277 4001, England.

Page 3

AM-RRS3-XXX

Application Circuit

Part numbering

AM-RRS3-315

Receiver Module 315MHz

AM-RRS3-418

Receiver Module 418MHz

AM-RRS3-433

Receiver Module 433MHz

AM-RRQ3-315

Receiver Module 315MHz

AM-RRQ3-433

Receiver Module 433MHz

AM-RRQ3-868

Receiver Module 868MHz

Should you require further assistance, please call;

R. F. Solutions Ltd.,

Unit 21, Cliffe Industrial Estate,

South Street, Lewes,

E Sussex, BN8 6JL. England.

Tel +44 (0)1273 898 000. Fax +44 (0)1273 480 661.

Email sales@rfsolutions.co.uk

http://www.rfsolutions.co.uk

RF Solutions is a member of the Low Power Radio Association.

Information contained in this document is believed to be accurate , however no representation or warranty is given and no liability is assumed by R.F. Solutions Ltd. with respect to the accuracy of

such information. Use of R.F.Solutions as critical components in life support systems is not authorised except with express written approval from R.F.Solutions Ltd.

RF Receiver

1 2 3

11

15

7

5

7

9

4

3

RF600D

17

14

13

12

11

10

2

1

18

OP3

OP4

GND

ECLK

IN

OP1

Vcc

Sleep

LKIN

SD1

LRN

OP2

LB

Vcc

1K

Ω

1K

Ω

Learn

Switch

Option

Link

Serial Data

Output

Vcc

O/P 1

O/P 2

O/P 3

O/P 4

Transmitter

Low Battery

Status

LED

22K

Ω

L

M

15K

Ω
