background image
DS059_2 Jul ‘01
©2001 Reg. No. 227 4001, ENGLAND
Page 2
FM SIL TRANSMITTER MODULE
FM-RTF3-XXX
Mechanical Dimensions
Pin Description
Pin Number
Name
Description
1
EA
External Antenna
2
IN
Data input
6
GND
Ground, Connect to RF earth return path
7
Vcc
Supply Voltage
Typical Application
Antenna Configuration
1
2
6 7
Component Side
22.86mm
11.43mm
2.54mm 10.16mm
Pins on "0.1 pitch
Pin Dimentions :
0.25mm x 0.50mm
A0
A1
A2
A3
A4
A5
A6
A7
VSS
AD8
AD9
AD10
AD11
TE\
OSC2
OSC1
DOUT
VDD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
HT12E
ROSC
+5V
ANTENNA
RFT3-XXX
+5V
1 2
6 7
RF
17.3cm @ 433MHz
RF GND
RF
Loop Antenna Area
4 To 10cm
2
Track Width
1mm
Capacitor 1.5 - 5pF
Fixed or Variable
RF
34 Turns of enamelled copper wire diameter 0.5mm
close wound on 2.5mm diameter former
Helical Coil Antenna
Loop Antenna
Whip Antenna
