Mclennan Servo Supplies Ltd. Tel: +44 (0)8707 700 700 www.mclennan.co.uk

Issue 002

Performance using MSE570 with alternative supply voltages

Size 17 hybrid motors:

Size 23 high speed hybrid motors:

Size 34 high speed hybrid motor:

Coils in parallel, 1.2 amps per phase

0.9 amps per phase

Coils in parallel, 3.5

amps per phase

17HS-020

0

2

4

6

8

10

12

0

2500

5000

7500

10000 12500 15000

half steps per sec. ( 0.9 degrees )

36V

40V

17HS-240

0

2

4

6

8

10

12

14

16

0

2500 5000 7500 10000 12500 15000

half steps per sec. ( 0.9 degrees )

36V

40V

2.3 amps per phase

23HS 104 Mk 2

0

5

10

15

20

25

30

35

40

0

5000

10000

15000

20000

half steps per sec. ( 0.9 degrees )

36V

40V

, Coils in parallel , 2.1 amps per phase

23HS 309 Mk 2

0

5

10

15

20

25

30

35

40

0

5000

10000

15000

20000

half steps per sec. ( 0.9 degrees )

36V

40V

Coils in parallel, 3.5 amps per phase

34HS-109

0

20

40

60

80

100

0

5000

10000

15000

20000

half steps per sec ( 0.9 degrees )

36V

40V
