IS25LE01GG

IS25WE01GG

Integrated Silicon Solution, Inc.- www.issi.com

179

Rev. A3

10/02/2025

9. ELECTRICAL CHARACTERISTICS

9.1 ABSOLUTE MAXIMUM RATINGS (1)

Storage Temperature

-65°C to +150°C

Input Voltage with Respect to Ground on All Pins

-0.5V to VCC + 0.5V

All Output Voltage with Respect to Ground

-0.5V to VCC + 0.5V

VCC

IS25LE

-0.5V to +6.0V

IS25WE

-0.5V to +2.5V

Note:

1. Applied conditions greater than those listed in “Absolute Maximum Ratings” may cause permanent damage to the

device. This is a stress rating only and functional operation of the device at these or any other conditions above

those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum

rating conditions for extended periods may affect reliability.

9.2 OPERATING RANGE

Operating Temperature

Extended Grade I

-40°C to 85°C

Extended Grade E

-40°C to 105°C

Automotive Grade A1

-40°C to 85°C

Automotive Grade A2

-40°C to 105°C

VCC Power Supply

IS25LE

2.7V (VMIN) – 3.6V (VMAX); 3.0V (Typ)

IS25WE

1.65V (VMIN) –1.95V (VMAX); 1.8V (Typ)
