AD8273
Rev. 0 | Page 9 of 16
1µs/DIV
Figure 22. Small Signal Pulse Response with 500 pF Capacitor Load, Gain = 2
1µs/DIV
Figure 23. Small Signal Pulse Response for 100 pF Capacitive Load,
Gain = ½
0
10
20
30
40
50
60
70
80
90
100
0
20
40
60
80
100
120
140
160
180
200
CAPACITANCE (pF)
2.5V
18V
5V
15V
Figure 24. Small Signal Overshoot vs. Capacitive Load, G = ½,
No Resistive Load
18V
15V
5V
2.5V
0
10
20
30
40
50
60
70
80
90
100
0
20
40
60
80
100
120
140
160
180
200
CAPACITANCE (pF)
Figure 25. Small Signal Overshoot vs. Capacitive Load,
G = ½, 600 Ω in Parallel with Capacitive Load
0
200
400
600
800
1000
1200
18V
15V
5V
2.5V
0
10
20
30
40
50
60
70
80
90
100
CAPACITANCE (pF)
Figure 26. Small Signal Overshoot vs. Capacitive Load,
G = 2, No Resistive Load
0
200
400
600
800
1000
1200
18V
2.5V
0
10
20
30
40
50
60
70
80
90
100
CAPACITANCE (pF)
15V
5V
Figure 27. Small Signal Overshoot vs. Capacitive Load,
G = 2, 600 Ω in Parallel with Capacitive Load
