ADL5519ACPZ-R7 데이터시트(PDF) 3 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADL5519ACPZ-R7 데이터시트(HTML) 3 Page - Analog Devices |
|
|
3 / 40 page  ADL5519 Rev. 0 | Page 3 of 40 SPECIFICATIONS Supply voltage, VP = VPSR = VPSA = VPSB = 5 V, CLPF = 1000 pF, TA = 25°C, 50 Ω termination resistor at INHA, INHB, unless otherwise noted. Table 1. Parameter Conditions Min Typ Max Unit SIGNAL INPUT INTERFACE INHA, INHB (Pin 25, Pin 32) Specified Frequency Range 0.001 10 GHz DC Common-Mode Voltage VP − 0.7 V MEASUREMENT MODE, 100 MHz OPERATION ADJA (Pin 21) = 0.65 V, ADJB (Pin 4) = 0.7 V; OUTA, OUTB (Pin 15, Pin 10) shorted to VSTA, VSTB (Pin 17, Pin 8); OUTP, OUTN (Pin 13, Pin 12) shorted to FBKA, FBKB (Pin 14, Pin 11), respectively; sinusoidal input signal; error referred to best-fit line using linear regression between PINHA, PINHB = −40 dBm and −10 dBm Input Impedance 1670||0.47 Ω||pF OUTA, OUTB ± 1 dB Dynamic Range 51 dB −40°C < TA < +85°C 42 dB OUTA, OUTB Maximum Input Level ±1 dB error −1 dBm OUTA, OUTB Minimum Input Level ±1 dB error −52 dBm OUTA, OUTB, OUTP, OUTN Slope1 −22 mV/dB OUTA, OUTB Intercept1 22 dBm Output Voltage (High Power In) OUTA, OUTB @ PINHA, PINHB = −16 dBm 0.7 V Output Voltage (Low Power In) OUTA, OUTB @ PINHA, PINHB = −40 dBm 1.37 V OUTP, OUTN Dynamic Gain Range ±1 dB error 50 dB −40°C < TA < +85°C 44 dB Temperature Sensitivity Deviation from OUTA, OUTB @ 25°C −40°C < TA < +85°C, PINHA, PINHB = −16 dBm ±0.25 dB 25°C < TA < 85°C, PINHA, PINHB = −40 dBm +0.16 dB −40°C < TA < +25°C, PINHA, PINHB = −40 dBm −0.6 dB Distribution of OUTP, OUTN from 25°C 25°C < TA < 85°C, PINHA = −16 dBm, PINHB = −30 dBm, typical error = −0.09 dB B ±0.25 dB −40°C < TA < +25°C, PINHA = −16 dBm, PINHB = −30 dBm, typical error = 0.25 dB ±0.4 dB 25°C < TA < 85°C, PINHA = −40 dBm, PINHB = −30 dBm, B typical error = 0.05 dB ±0.25 dB −40°C < TA < +25°C, PINHA = −40 dBm, PINHB = −30 dBm, typical error = −0.23 dB B ±0.45 dB Input A-to-Input B Isolation 80 dB Input A-to-OUTB Isolation Frequency separation = 1 kHz, PINHA = −50 dBm, PINHA – PINHB when OUTB/Slope = 1 dB 60 dB Input B-to-OUTA Isolation Frequency separation = 1 kHz, PINHB = −50 dBm, PINHB – PINHA when OUTA/Slope = 1 dB 60 dB MEASUREMENT MODE, 900 MHz OPERATION ADJA = 0.6 V, ADJB = 0.65 V; OUTA, OUTB shorted to VSTA, VSTB; OUTP, OUTN shorted to FBKA, FBKB, respectively; sinusoidal input signal; error referred to best fit line using linear regression between PINHA, PINHB = −40 dBm and −10 dBm B Input Impedance 925||0.54 Ω||pF OUTA, OUTB ± 1 dB Dynamic Range 54 dB −40°C < TA < +85°C 49 dB OUTA, OUTB Maximum Input Level ±1 dB error −2 dBm OUTA, OUTB Minimum Input Level ±1 dB error −56 dBm OUTA, OUTB, OUTP, OUTN Slope1 −22 mV/dB OUTA, OUTB Intercept1 20.3 dBm Output Voltage (High Power In) OUTA, OUTB @ PINHA, PINHB = −10 dBm 0.67 V Output Voltage (Low Power In) OUTA, OUTB @ PINHA, PINHB = −40 dBm 1.34 V |
|
