[2.Model Number Configuration]

■

■Rated Voltage

■

■Installation・・・・Wiring・・・・Buzzer

■

■LED Unit Color

： 12-24V DC

： 3-point Bolt Leg Mounting・Cabtyre Cord・No Buzzer

R ： Red

： 100-240V AC

： 2-point Hole Type Mounting・Terminal block・No Buzzer

Y ： Amber

： 2-point Hole Type Mounting・Terminal block・With Buzzer

G ： Green

B ： Blue

[mm]

Case

Number

Name

Material ・ Specification

PVC, M1JN : AWG22×5, M2JN : AWG18×2+AWG24×3

Waterproof Sheet

Silicone

Terminal block

Mounting Bracket

LCP GF,

Applicable wire size Solid Wire : 0.13-1.5mm

2 ,

Stranded Wire : AWG28-14

Cabtyre Cord

Globe

[3.Outer Dimensions]

KTN

KTB

B -

S F 1

- M

Drawing No.

Rev.

Page

■SF10-M1JN/SF10-M2JN

■SF10-M1KT□/SF10-M2KT□

2 / 4

SF10-M1JN-W18
