ＳＰＥＣＩＦＩＣＡＴＩＯＮＳ

Model

5 lights

ＷＥ－５０２ＦＢ

ＷＥＰ－５０２ＦＢ

4 lights

ＷＥ－４０２ＦＢ

ＷＥＰ－４０２ＦＢ

3 lights

ＷＥ－３０２ＦＢ

ＷＥＰ－３０２ＦＢ

Surface of cover

Chromium plating

Not plating

(Light gray)

Rated voltage

24V AC/DC（50/60Hz）

Operating voltage

Rated voltage±10%

Current

consumption

Per light

Buzzer

Red

Amber

Green

Blue

White

Typ.

24 mA

17 mA

40 mA

Max.

28 mA

27 mA

23 mA

50 mA

（

Rush current : 250mA）

Operating temperature range

(Relative humidity）

- 30℃ ～ + 60℃

（

Less than 90%）

Mounting place

Indoor only

Mounting direction

Upright,Updown,Sideways

Protection rating

IP54 (Mounting direction : Upright)

Vibration proof

19.6 m/s2 （30Hz）

Insulation resistance

To be measured by an insulation measuring device of 500VDC between the

terminals and the chassis.

More than 1MΩ

Withstand voltage

500VAC being applied between the terminals and the chassis for 1 minute.

Not braking insulation

Flashing cycle

60±12 flashes per minute

Buzzer

Sound level

90dB（at 1m）

Tone

Buzzer1：pipipi Buzzer2：beep beep

Luminous intensity

Red

Amber

Green

Blue

White

600 mcd or more 800 mcd or more 2000 mcd or more 600 mcd or more 1800 mcd or more

Mass

3 lights

4 lights

5 lights

0.30 kg

0.33 kg

0.35 kg

Ｎｏ．ＷＥ－５０２ＦＢ－W１８Ａ－１＿２

●

This product confirms to the CE requirements and CE Marking is indicated.

●

Recognized as UL standard. (Standard No.UL508, File No. E215660)

●

This product complies with the RoHS Directive(DIRECTIVE 2002/95/EC)
