AD8671/AD8672/AD8674

Rev. C | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

Table 3.1

Parameter

Rating

Supply Voltage

36 V

Input Voltage

Differential Input Voltage

±0.7 V

Output Short-Circuit Duration

Indefinite

Storage Temperature Range

All Packages

–65°C to +150°C

Operating Temperature Range

All Packages

–40°C to +125°C

Junction Temperature Range

All Packages

–65°C to +150°C

Lead Temperature Range (Soldering, 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Table 4. Package Characteristics

Package Type

Unit

8-Lead MSOP (RM)

190

44

°C/W

8-Lead SOIC_N (R)

158

43

°C/W

14-Lead SOIC_N (R)

120

36

°C/W

14-Lead TSSOP (RU)

180

35

°C/W

device soldered in circuit board for surface-mount packages.

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on

the human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
