AD8661/AD8662/AD8664

Rev. D | Page 7 of 16

ABSOLUTE MAXIMUM RATINGS

Table 5.

Parameter

Rating

Supply Voltage

18 V

Input Voltage

Differential Input Voltage

18 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−60°C to +150°C

Operating Temperature Range

R-8, RM-8, R-14, and RU-14

−40°C to +125°C

CP-8-2

−40°C to +85°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature, Soldering (60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

soldered in a circuit board for surface-mount packages.

Table 6. Thermal Resistance

Package Type

Unit

8-Lead SOIC_N

121

43

°C/W

8-Lead LFCSP_VD

751

181

°C/W

8-Lead MSOP

142

44

°C/W

14-Lead SOIC_N

88.2

56.3

°C/W

14-Lead TSSOP

114

23.3

°C/W

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on

the human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
