AD8571/AD8572/AD8574

Rev. C | Page 19 of 24

CAPACITIVE LOAD DRIVE

The optimum value for the resistor and capacitor is a function

of the load capacitance and is best determined empirically since

actual C

The AD857x have excellent capacitive load driving capabilities

and can safely drive up to 10 nF from a single 5 V supply.

Although the device is stable, capacitive loading limits the

bandwidth of the amplifier. Capacitive loads also increase the

amount of overshoot and ringing at the output. An RC snubber

network, shown in

LOAD

includes stray capacitances and can differ substantially

from the nominal capacitive load. Table 5 shows some snubber

network values that can be used as starting points.

Table 5. Snubber Network Values for Driving Capacitive Loads

Figure 59, can be used to compensate the

amplifier against capacitive load ringing and overshoot.

(nF)

Rx (Ω)

LOAD

200

1 nF

VOUT

VIN

200mV p-p

AD8571/

AD8572/

AD8574

4.7nF

0.47µF

60Ω

–

4.7

0.47 μF

10 μF

POWER-UP BEHAVIOR

On power-up, the AD857x settle to a valid output within 5 μs.

Figure 61 shows an oscilloscope photo of the output of the

amplifier along with the power supply voltage.

Figure 59. Snubber Network Configuration for Driving Capacitive Loads

Figure 62 shows

the test circuit. With the amplifier configured for unity gain, the

device takes approximately 5 μs to settle to its final output

voltage, hundreds of microseconds faster than many other

autocorrection amplifiers.

Although the snubber does not recover the loss of amplifier

bandwidth from the load capacitance, it does allow the amplifier

to drive larger values of capacitance while maintaining a minimum

of overshoot and ringing. Figure 60 shows the output of an

AD857x driving a 1 nF capacitor with and without a snubber

network.

5µs

VOUT

V+

BOTTOM TRACE = 2V/DIV

TOP TRACE = 1V/DIV

10μs

100mV

VS = 5V

CLOAD = 4.7nF

WITHOUT

SNUBBER

WITH

SNUBBER

Figure 61. AD857x Output Behavior on Power-Up

Figure 60. Overshoot and Ringing Are Substantially

Reduced Using a Snubber Network

100kΩ

VSY = 0V TO 5V

VOUT

AD8571/

AD8572/

AD8574

Figure 62. AD857x Test Circuit for Turn-On Time
