background image
Lubricator
MS6-LOE-AGE-R
Part number: 8232972
General operating condition
Data sheet
Feature
Value
Size
6
Series
MS
Mounting position
Vertical +/- 5°
Structural design
Proportional standard oil mist lubricator
Max. oil capacity
75 cm³
Bowl guard
Plastic bowl guard
Symbol
00991532
Operating pressure
0.1 MPa ... 1.6 MPa
Operating pressure
1 bar ... 16 bar
Operating pressure
14.5 psi ... 232 psi
Minimum flow rate for lubricator function
50 l/min
Normal nominal flow rate (normalized to DIN 1343)
7200 l/min
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Inert gas
Information on operating and pilot media
Operation with oil lubrication possible
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
LABS (PWIS) conformity
VDMA24364-B1/B2-L
Storage temperature
-10 °C ... 60 °C
For use in the food industry
See supplementary material information
Temperature of medium
-10 °C ... 60 °C
Oil viscosity
ISO VG 32
Ambient temperature
-10 °C ... 60 °C
Product weight
900 g
Type of mounting
With accessories
Pneumatic connection 1
G3/4
Pneumatic connection 2
G3/4
Note on materials
RoHS-compliant
Material of sub-base
Die-cast aluminum
Seals material
NBR
Housing material
Die-cast aluminum
Material of bowl
PC
2/11/26 - Subject to change - Festo SE & Co. KG
1/1
