Shield Termination

SolderSleeve Shield Terminators (Continued)

Cable OD

Part No. (MIL Part Number and Raychem Part No.) by Lead Option

Preinstalled Lead Option*

Jacket OD

Shield OD

No Preinstalled Lead

20 AWG

22 AWG

Max

Min

MIL

Raychem

MIL

Raychem

MIL

Raychem

1.95 [0.075]

0.9 [.035]

M83519/1-1

S01-01-R

M83519/2-1

S02-01-R

M83519/2-6

S02-06-R

2.7[0.105]

1.40 [.055]

M83519/1-2

S01-02-R

M83519/2-2

S02-02-R

M83519/2-7

S02-07-R

4.3 [0.170]

2.15 [.085]

M83519/1-3

S01-03-R

M83519/2-3

S02-03-R

M83519/2-8

S02-08-R

6.0 [0.235]

3.30 [.130]

M83519/1-4

S01-04-R

M83519/2-4

S02-04-R

M83519/2-9

S02-09-R

7.0 [0.275]

4.30 [.170]

M83519/1-5

S01-05-R

M83519/2-5

S02-05-R

M83519/2-10

S02-10-R

Jacket OD

Shield OD

Preinstalled Lead Option*

Max.

Min.

24 AWG

26 AWG

1.95 [0.075]

0.9 [.035]

M83519/2-11

S02-11-R

M83519/2-16

S02-16-R

2.7 [0.105]

1.40 [.055]

M83519/2-12

S02-12-R

M83519/2-17

S02-17-R

4.3[0.170]

2.15 [.085]

M83519/2-13

S02-13-R

M83519/2-18

S02-18-R

6.0 [0.235]

3.30 [.130]

M83519/2-14

S02-14-R

M83519/2-19

S02-19-R

7.0 [0.275]

4.30 [.170]

M83519/2-15

S02-15-R

M83519/2-20

S02-20-R

*See Table G for lead description.

M83519 is the qualified product listed in SAE-AS83519 (formerly MIL-S-83519) . The series features a thermochromic temperature indicator to assist in termi-

nation and inspection. The Raychem part number is permanently marked on the sleeve.

Thermochromic Temperature Indicator

The M83519 (S01 and S02) series terminators contain

a colored thermochromic temperature indicator that

exhibits a distinct color change when surfaces have

reached wetting temperature. This color change gives both

manufacturing and Quality Control an aid in the inspection

of the completed termination.

Table C. S01/S02 M83519

Series

Thermochromic Temperature Indicator

The S03 series terminators contain a colored ther-

mochromic temperature indicator that exhibits a

distinct color change when surfaces have reached wetting

temperature. This color change gives both Manufacturing

and Quality Control an aid in the inspection of the

completed termination.

Table D. S03 Series

Cable OD

Part No.

Preinstalled Lead Option*

Jacket OD

Shield OD

Max.

Min.

Tin plated Braid Strap

Nickel plated Braid Strap

1.95 [0.075]

0.9 [.035]

S03-01-R

S03-06-R

2.7 [0.105]

1.40 [.055]

S03-02-R

S03-07-R

4.3 [0.170]

2.15 [.085]

S03-03-R

S03-08-R

6.0 [0.235]

3.30 [.130]

S03-04-R

S03-09-R

7.0 [0.275]

4.30 [.170]

S03-05-R

S03-10-R

*See Table G for lead description.
