UFS3-37B417 | UFS

FORK SENSORS

Ambient data

Ambient operating temperature

+5 °C ... +55 °C 1)

Ambient temperature, storage

–20 °C ... +70 °C

Shock load

According to EN 60068-2-27

EMC

EN 60947-5-2 2)

UL File No.

NRKH.E191603 & NRKH7.E191603

1) Do not bend below 0 °C.

2) The sensor complies with the Radio Safety Requirements (EMC) for the industrial sector (Radio Safety Class A). It may cause radio interference if used in a residen-

tial area.

Smart Task

Smart Task name

Base logics

Classifications

ECLASS 5.0

27270909

ECLASS 5.1.4

27270909

ECLASS 6.0

27270909

ECLASS 6.2

27270909

ECLASS 7.0

27270909

ECLASS 8.0

27270909

ECLASS 8.1

27270909

ECLASS 9.0

27270909

ECLASS 10.0

27270909

ECLASS 11.0

27270909

ECLASS 12.0

27270909

ETIM 5.0

EC002720

ETIM 6.0

EC002720

ETIM 7.0

EC002720

ETIM 8.0

EC002720

UNSPSC 16.0901

39121528

Connection/Pin assignment

Connection type

Male connector M8, 4-pin

Pin assignment

BN 1 + (L+)

WH 2 MF

BU 3 - (M)

BK 4 Q/C

4

FORK SENSORS | SICK

Product data sheet | 2024-03-28 09:44:02

Subject to change without notice
