Video Monitor Kit

Page <1>

23/06/12 V1.1

www.element14.com

www.farnell.com

www.newark.com

www.cpc.co.uk

Important Notice : This data sheet and its contents (the "Information") belong to the members of the Premier Farnell group of companies (the "Group") or are licensed to it. No licence is granted for the use of

it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces

all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use

made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted.

Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising)

is excluded. This will not operate to limit or restrict the Group's liability for death or personal injury resulting from its negligence. pro-SIGNAL is the registered trademark of the Group. © Premier Farnell plc 2012.

Features:

•• 2 video inputs

•• 1 audio input

•• 1 video output

•• Left and right reverse image

•• Low power consumption

Specifications:

Display Screen

: 4 inches (10 cm)

Active Area

: (W) 82.1 × (H) 61.8 mm

Element

: Colour TFT LCD

Resolution

: (W) 480 × (H) 234 mm

Video System

: PAL : fH : 15.625 KHz

fV : 50 Hz

fC : 4.43 MHz

Power Source

: 12 V dc

Range of Operating Voltage

: 9 V dc to 13 V dc

Viewing Angle

: L / R : 45°C

Top

: 30°C

Down

: 60°C

Maximum Power Consumption

: 340 mA, 5 W

Operating Temperature

: 0°C to 60°C

Storage Temperature

: -20°C to 80°C

Operating Humidity

: 85% RH

Storage Humidity

: 85% RH

Overall Dimension

: (W) 139 × (H) 115 × (D) 36 mm

Reverse Image

: Left and right

Accessories

Rechargeable battery × 1

Carry bag × 1

Adaptor × 1

Power cord ×1

Carry belt × 1, waist belt × 1

RCA / BNC connector × 3

Part Number Table

Description

Part Number

Video Monitor Kit, 4 Inches

LSM413
