1 / 39 page

June 2007

Rev 8

1/39

1

M95512-W

M95512-R

512 Kbit Serial SPI bus EEPROM

with high speed clock

Features

■

Compatible with SPI bus serial interface

(Positive Clock SPI modes)

■

Single supply voltage:

– 2.5 V to 5.5 V for M95512-W

– 1.8 V to 5.5 V for M95512-R

■

High speed

– 5 MHz clock rate

– 5 ms Write time

■

Status Register

■

Hardware Protection of the Status Register

■

Byte and Page Write (up to 128 Bytes)

■

Self-timed programming cycle

■

Adjustable size read-only EEPROM area

■

Enhanced ESD Protection

■

More than 1 000 000 Write cycles

■

More than 40-year data retention

■

Packages

– ECOPACK® (RoHS compliant)

SO8 (MN)

150 mils width

TSSOP8 (DW)

169 mils width

www.st.com
