1 / 24 page

1/24

February 2005

M24512

512 Kbit Serial I²C Bus EEPROM

FEATURES SUMMARY

■

Two-Wire I2C Serial Interface

Supports 400 kHz Protocol

■

Supply Voltage Ranges:

–

1.8V to 5.5V (M24512

− R)

–

2.5V to 5.5V (M24512

− W)

■

Write Control Input

■

BYTE and PAGE WRITE (up to 128 Bytes)

■

RANDOM and SEQUENTIAL READ Modes

■

Self-Timed Programming Cycle

■

Automatic Address Incrementing

■

Enhanced ESD/Latch-Up Protection

■

More than 100,000 Erase/Write Cycles

■

More than 40-Year Data Retention

Table 1. M24512 devices

Figure 1. Packages

Reference

Part Number

M24512

− W

M24512

− R

PDIP8 (BN)

8

1

SO8 (MW)

208 mil width

TSSOP8 (DW)

8

1

8

1

SO8 (MN)

150 mil width
