SOT23-5

Features

•

Low power consumption: 235 µA typ. at 5 V

•

Supply voltage: 3 V to 16 V

•

Gain bandwidth product: 900 kHz typ.

•

Offset voltage: 3 mV maximum

•

Low input bias current: 1 pA typ.

•

High tolerance to ESD: 4 kV

•

Wide temperature range: -40 °C to +125 °C

•

Rail-to-Rail input and output

•

SOT23-5 package

Applications

•

Industrial and automotive signal conditioning

•

Active filtering

•

Power savings in power-conscious applications

•

Medical instrumentation

•

High impedance sensors

•

Easy interfacing with high impedance sensors

Description

The LMC7101 operational amplifier benefits from STMicroelectronics® 16 V CMOS

technology to offer state-of-the-art accuracy and performance in the smallest

industrial packages. The LMC7101 offers an outstanding speed/power consumption

ratio, 900 kHz gain bandwidth product while consuming only 250 µA at 16 V.

Such features make the LMC7101 ideal for sensor interfaces and industrial signal

conditioning. The wide temperature range and high ESD tolerance ease use in harsh

automotive applications.

Product status link

LMC7101

Related products

See TSX631

for reduced power

consumption

(45 μA, 200 kHz)

See TSX921

for higher gain

bandwidth products

(10 MHz)

Tiny, low power, 16 V single operational amplifier for cost-optimized systems

LMC7101

Datasheet

DS13567 - Rev 1 - November 2020

For further information contact your local STMicroelectronics sales office.

www.st.com
