w w w.g e eh y. co m
P ag e 8
Figure 2 Distribution Diagram of APM32E103xCxE Series LQFP100 Pins
LQFP100
1
PE2
2
PE3
3
PE4
4
PE5
5
PE6
6
VBAT
7
PC13-TAMPER-RTC
8
PC14-OSC32_IN
9
PC15-OSC32_OUT
10
VSS_5
11
VDD_5
12
OSC_IN
13
OSC_OUT
14
NRST
15
PC0
16
PC1
17
PC2
18
PC3
19
VSSA
20
VREF-
21
VREF+
22
VDDA
23
PA0-WKUP
24
PA1
25
PA2
75
VDD_2
74
VSS_2
73
NC
72
PA13
71
PA12
70
PA11
69
PA10
68
PA9
67
PA8
66
PC9
65
PC8
64
PC7
63
PC6
62
PD15
61
PD14
60
PD13
59
PD12
58
PD11
57
PD10
56
PD9
55
PD8
54
PB15
53
PB14
52
PB13
51
PB12
