UPC251, UPC1458

R03DS0118EJ0100 Rev.1.00

Page 2 of 8

Feb.18.25

ABSOLUTE MAXIMUM RATINGS (TA = 25°C)

Parameter

Symbol

UPC251G2

UPC1458G2

Unit

Voltage between V+ and V− Note1

V+ - V-

-0.3 ~ +36

V

Differential Input Voltage

VID

±30

V

Input Voltage Note 2

VI

V- -0.3 ~ V+ +0.3

V

Output applied Voltage Note3

VO

V- -0.3 ~ V+ +0.3

V

Total Power Dissipation Note4

PT

440

mW

Output Short Circuit Duration Note5

Indefinite

s

Operating Ambient Temperature

TA

-40 ~ +85

-20 ~ +80

°C

Storage Temperature

Tstg

-55 ~ +125

°C

【

Note】 1. Reverse connections of supply voltage can cause destruction.

2. The input voltage should be allowed to input without damage or destruction. Even during the transition period

of supply voltage, power on/off etc., this specification should be kept. The normal operation will establish

when the both inputs are within the Common Mode Input Voltage Range of electrical characteristics.

3. This specification is the voltage which should be allowed to supply to the output terminal from external without

damage or destruction. Even during the transition period of supply voltage, power on/off etc., this specification

should be kept. The output voltage of normal operation will be the Output Voltage Swing of electrical

characteristics.

4. Thermal derating factor is –4.4 mW/°C when operating ambient temperature is higher than 25 °C.

5. Pay careful attention to the total power dissipation not to exceed the absolute maximum ratings and Note 4.

RECOMMENDED OPERATING CONDITIONS

Parameter

Symbol

MIN.

TYP.

MAX.

Unit

Power Supply Voltage (Dual Supply)

V±

±7.5

±16

V

Power Supply Voltage (V- = GND)

V+

+15

+32

V

Output Current

IO

±2

±5

mA
