HyperLink Wireless

900 MHz 13 dBi Yagi Antennas for

ISM, GSM and Wireless LAN Systems

Model:

HG913Y

Applications and Features

Applications:



900MHz ISM Band



Wireless LAN systems



Point to multipoint applications



Non Line of Sight (NLOS)



GSM



RFID



SCADA



Wireless Video Links



900MHz Cellular

Features:



Superior performance



Heavy duty steel construction



All weather operation



Heavy-duty 1/2" stainless steel boom



Solid 1/8" elements



18 inch coax lead



Can be installed for either vertical or

horizontal polarization



1/8" thick plated steel mounting plate



RoHS Compliant

Product Description

Superior Performance

The HyperGain

® HG9013Y High-Performance Yagi Antennas combines high gain with a wide beam-width. They are ideally

suited for directional applications in the 900MHz ISM and GSM bands. Typical applications include 900MHz Wireless LAN,

SCADA, Wireless Video Links, 900 MHz Cellular, Non Line of Sight (NLOS) applications and point to multi-point systems.

External interference of this antenna is minimized due to the excellent front to back ratio. These antennas come with a 18" coax

lead terminated with an N-Female connector. It can be installed for either vertical or horizontal polarization

Rugged and Weatherproof

This antenna features a heavy-duty 1/2" stainless steel boom and solid 1/8" elements. Secure mounting is assured by a 1/8"

thick plated steel mounting plate and two plated steel U-bolts.
