900 MHz 5dBi Rubber Duck Antenna RIGID RP-TNC Plug Connector HG905RDR-RTP

900 MHz 5dBi Rubber Duck Antenna RIGID RP-TNC Plug Connector

Features

•

Better Performance than Most Stock AP Antennas

•

Flexible “Rubber Duck” Antenna

•

RP-TNC Plug Connector

Applications

•

900 MHz Digital Spread Spectrum Radios

• 900 MHz ISM Band

•

LPWAN, LoRA, IoT, M2M Applications

•

900 MHz Telemetry Products

•

Cellular Band Applications

Description

The HG905RDR-RTP from L-com is an economical yet superior performance omnidirectional “rubber-duck” antenna designed for the

900 MHz ISM band. It features a RIGID Reverse Polarity TNC (RP-TNC) male connector, allowing superior weatherproofing for indoor

and outdoor applications. It is a coaxial sleeve design with an omni-directional pattern. It is ideally suited for 900MHz ISM band applica-

tions as well as cellular and LPWAN applications.

The L-com high performance rubber-duck HG905RDR-1-RTP is a flexible antenna providing broad coverage and 5.0 dBi gain.

Measuring 16.0 inches long, this 5.0 dBi antenna makes a great upgrade to OEM supplied antennas offering much larger coverage

area and stronger signals. It is suitable as a replacement RF antenna for 900 MHz radios that are equipped with RP-TNC connectors.

This 900 MHz ISM antenna, as well as our wide selection of superior quality RF parts, ship same day. Contact our knowledgeable and

friendly technical support and sales staff for your answers on antennas or other L-com products.

Configuration

Design

Rubber Duck

Band Type

Single

Polarization

Vertical

Connector Type

TNC Male Reverse Polarity

Number of Ports

1

Housing Material and Plating

Black

Electrical Specifications

Description

Minimum

Typical

Maximum

Units

Frequency Range

900

930

MHz

Input VSWR

2.5:1

Impedance

50

Ohms

Gain

5

dBi

Input Power

50

Watts

.

Mechanical Specifications

HG905RDR-RTP
