ON-BOARD SERIES

● Space saving and FG reinforcement at design stage of PC board.

● Supplied with embossed tape for automated mounting by chip mounter.

● Suitable management for emission and ESD immunity.

Feature

Grounding components, with support for automated

mounting on PC board.

●Notes for On-Board series

　Please contact our sales department for mounting specifications such as recommended pad dimensions, etc.

　Trial mounting using our products is required prior to purchase. Please check the notes indicated on the back cover.

　Galvanic corrosion may occur by contact with other metals.

　With regard to sales lot and delivery lead time, please contact our sales department.

ON-BOARD CONTACT

Upper faces of mounted make

contact with chassis, PC

board and component, etc.

SIDE CONTACT

Side face of mounted parts

makes contact with chassis,

PC board and metal frame, etc.

ON-BOARD PLATE

Reinforcement at contact points

provided for reliable grounding.

ON-BOARD LUG TERMINAL

Improved grounding reliability

at screw area.

ON-BOARD CLAMP

Space-saving cable wiring on

PC boards.

ON-BOARD SHIELDING GUIDE

Displacement prevention mechanism

improves shielding can grounding.

ON-BOARD CLIP

Clip mechanism enables stable fixing

and grounding for shielding can.
