HyperLink 2.4 GHz 8.5 dBi Omnidirectional Wireless LAN Marine

Antenna Model: HG2409UM

Features

Applications:



2.4 GHz ISM Band



IEEE 802.11b, 802.11g and 802.11n Wireless LAN



Bluetooth®



WiFi



Multipoint applications



Marine, RV and Campground Public Wireless Hotspots



Can be used on Boats, RV's and Campers

Features:



Superior performance



Compact, lightweight design



Durable UV-stable fiberglass radome



Sealed end cap and drain holes in base



All weather operation



Mounts to standard 1"-14 thread marine antenna mounts



Features side-fed 3' coax lead with Reverse Polarity SMA-Plug connector



Optional Marine Mount available

Shown on Optional

Marine Antenna Mount

Description

High Performance

The HyperGain® HG2409UM-RSP is a high performance omnidirectional WiFi antenna designed for the 2.4 GHz ISM band. This

compact and lightweight antenna is ideally suited for IEEE 802.11b, 802.11g and 802.11n wireless LANs, public wireless

hotspots, Bluetooth® and other multipoint applications where high gain and wide coverage is desired. Designed for marine

applications, this antenna features a 3' side-fed coax lead with a reverse-polarity SMA Plug connector. Optional

extension/adapters cables are also available. The 1"-14 threaded base of this antenna allows it to be used with standard 1"-14

thread marine antenna mounts.

All Weather Operation

Constructed for all weather operation, the HG2409UM-RSP features sealed collinear brass elements inside a durable UV-stable

machine white fiberglass radome. A sealed end cap and drain holes in the base help prevent moisture build-up inside the

antenna.
