Play mode　（Setting with selection switch）

I

The message No.1 plays.

( Revolving Light doesn't work. )

Test Mode

G

CH input : CH1 - CH4 Number of playing messages : 4

Message play is possible only while the input is held.

The play stops when the input stops.

Bit input・Hold play mode

H

CH input : CH1 - CH4 Number of playing messages : 15

Message play is possible only while the input is held.

The play stops when the input stops.

Binary input・Hold play

mode

E

CH input : CH1 - CH4 Number of playing messages : 4

When the next message is input while message is being play, the

message that is being played is stopped and the latest input message

is playing.

Bit input･Latest input priority

play mode

F

CH input : CH1 - CH4 Number of playing messages : 15

When the next message is input while message is being play, the

message that is being played is stopped and the latest input message

is playing.

Binary input･Latest input

priority play mode

C

CH input : CH1 - CH3 Number of playing messages : 3

CH4 : Input reduces the volume by 20dB.

Bit input・Sound

reduction mode

D

CH input : CH1 - CH3 Number of playing messages : 7

CH4 : Input reduces the volume by 20dB.

Binary input・Sound

reduction mode

A

CH input : CH1 - CH4

Number of playing messages : 4

Bit Input Mode

B

CH input : CH1 - CH4

Number of playing messages : 15

Binary Input Mode

図番

改訂

ページ

E

1 2 3 4

ON

1 2 3 4

ON

1 2 3 4

ON

1 2 3 4

ON

1 2 3 4

ON

1 2 3 4

ON

1 2 3 4

ON

1 2 3 4

ON

1 2 3 4

ON

～Caution on copyright～

If a work that was recorded or copied from music CDs or other media is used at public places,

law enforcement for copyright infringement may be imposed. When using a work that was

recorded or copied from music CDs or other media, be sure to obtain permission from the author.

In addition, the copyright of audio/music data which are distributed or sold by PATLITE

Corporation belongs to PATLITE. It is strictly prohibited to copy/reprint the partial or whole

contents of audio/music data of PATLITE Corporation or to transfer/sell them on computer

networks etc. without the permission of the right holder.

2/3

RT-24VF-W18
