FEATURES

LINE VOLTAGE 90 - 264 VAC

SINGLE OUTPUT MAX 8W

DESIGNED FOR ON LINE CHARGING OF

MOBILE PHONES

EMC COMPLIANCE ACCORDING TO EU

AND US DIRECTIVES

SAFETY

APPROVAL

ACCORDING

TO

EN60950

CE AND UL MARKED. AUSTRALIA, UK,

SOUTH AFRICA

AND CHINA MARKING

UPON REQUEST

OUTPUT CURRENT AND VOLTAGE LEVELS

ACCORDING TO CUSTOMER REQUIRE-

MENTS

OUTPUT VOLTAGE PRECISION: +/- 5%

OUTPUT CURRENT PRECISION : +/- 12%

OUTPUT RIPPLE VOLTAGE <100 mVpp

INPUT FUSE PROTECTION

OUTPUT SHORT CIRCUIT PROTECTION

2 WIRES DC CORD TERMINATED WITH

ANY CUSTOM CONNECTOR

AVAILABLE WITH A VARIETY OF AC PLUGS

LOW STAND BY POWER

DESCRIPTION

The Fast Charger MISTRAL has been designed

for charging NiMH and NiCd batteries in hand

held mobile phones. MISTRAL is a low cost high

efficiency AC/DC switching mode constant volt-

age & current generator. The output voltage and

current levels are set up by design in accordance

with customer requirements.

January 2000

®

PRODUCT VIEW

(Robin Housing, all plug types)

ORDERING NUMBER: GSAC-xxCCCy

MISTRAL

AC/DC Multirange FAST CHARGER

Rev. 01

Plug Type:

Part Number:

EURO

GSAC-xxCCC1

UK

GSAC-xxCCC2

US

GSAC-xxCCC3

AUSTRALIA

GSAC-xxCCC4

INDIA/S. Africa

GSAC-xxCCC5

CHINA

GSAC-xxCCC6

xx = Output Current level (2 Digits)

CCC= Customer Identifier (3 Digits)

y = plug type

1/4
