Specifications

System Type

LED Lighting System

Powered or Passive

Powered

Power Consumption LEDs

14 watts per LED

(4 LEDs, 56 watts per pod)

Power Consumption

200VA, 1.7A @ 120VAC Nominal

Stand Mount Size

1 3/8-inch Round

Pole Through Design

Manual Controls

Master Brightness

Lamp Colours

Effect Modes

Colour Chase / Colour Fade /

Audio Chase / Bluetooth

Bluetooth Control App

IOS & Android

DMX

Shielded 3-pin XLR Cable

Sound Active Mode

Integrated Microphone

Audio Input

Line Level or Speaker Level

Yorkville Controller

LP-C12 or LP-C4

Dimensions (LWH inches)

31 x 4.8 x 8

Dimenstions (LWH cm)

78.8 x 12.25 x 20.4

Weight

14.6 lbs (6.6 kg)

Box Dimensions (LxWxH, inches)

34 x 10 x 10

Box Dimensions (LxWxH, cm)

86 x 25 x 25

Specifications subject to change without notice

Features

l

Four Pods each with Four RGBW LEDS

l

Bluetooth Compatible

l

Operates in Standalone Mode, Controlled Via Yorkville

Proprietary Communication Protocol, Integrated DMX I/O,

Bluetooth Control (IOS) and Android

l

Integrated Microphone for Sound Active mode

l

31 Pre-set Colors per Pod in Standalone Mode

l

Master Brightness Control

l

Audio Chase Input (Line Level or Speaker Level)

l

Pole Adapter goes right through unit allowing stacking of

multiple LP-LED’s or to be mounted under a loudspeaker

l

Made in Canada

Overview

Low profile design with convenient bar handles make the LP-LED4X easy

to transport. Innovative through-hole stand mount design allows multiple

units to be used on a standard speaker stand for large scale mobile appli-

cations. Contractors and touring companies will appreciate the integrated

flypoints that ensure safe installation or truss mounting in touring rigs, club

installs or theatre applications.

Our iOS App controls up to four individual LP-LED4X fixtures via Bluetooth,

and Android.

LP-LED4X

4 HEAD LED LIGHTING SYSTEM

yorkville.com

LP-LED4X

The iOS and Android App, via

Bluetooth, controls up to 4

individual LP-LED4X and

LP-LED2X fixtures.

Available for

FREE DOWNLOAD

Type: yorkville LP-control
