background image
KW CSLPM2.PC
DATASHEET
DATASHEET
2 | Version 1.7 | 2023-01-04
OSLON® Square Flat
KW CSLPM2.PC
The most compact 3 x 3 mm high power LED with an electrical-
ly isolated thermal pad allows for superior heat dissipation de-
signs. The flat package shape enhances color homogeneity due
to reduced color over angle variation. Extremely low thermal
resistance helps to maintain the efficiency remarkably high even
when driven at higher currents.
Applications
- Entertainment
- Transportation
Features
- Package: Ceramic package
- Chip technology: UX:3
- Typ. Radiation: 120° (Lambertian emitter)
- Color: Cx = 0.32, Cy = 0.33 acc. to CIE 1931 (● white)
- Corrosion Robustness Class: 2B
- Color temperature: 5000K - 6500K
- CRI: 70 (typ.)
- ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
