A22Z-R datasheet(1/40 Pages) OMRON

전자부품 데이터시트 검색엔진

ALLDATASHEET.CO.KR

A22Z-R 데이터시트(PDF) 1 Page - Omron Electronics LLC

부품명	A22Z-R

상세설명	Emergency Stop Pushbutton Switches (22-dia. or 25-dia.)

PDF	40 Pages

Scroll/Zoom	100%

제조업체	OMRON [Omron Electronics LLC]

홈페이지	http://www.omron.com/index3.html

Logo

1 / 40 page

New Product

Install in 22-dia. or 25-dia.

Panel Cutout (When Using a Ring)

• Direct opening mechanism to open the circuit when the

contact welds.

• Safety lock mechanism prevents operating errors.

• Lever for easily mounting and removing the Switch Blocks.

• Finger protection mechanism on Switch Unit provided as a

standard feature.

• Use 25-dia. ring to install in 25-dia. panel cutouts.

Types of Emergency Stop Pushbutton Switches

A22E

Screw Terminal Block Types ................................... from page 2

A22NE-P Push-in Plus Terminal Block Types ........................ from page 16

Common Items

Common Accessories / Tools................................................... from page 32

Safety Precautions..................................................................... from page 37

For the most recent information on models that have been certified for

safety standards, refer to your OMRON website.

Be sure to read the "Safety Precautions" on pages 15,

28, and 37.

Emergency Stop Pushbutton Switches (22-dia. or 25-dia.)

A22E/A22NE-P
