E5ED/E5ED-B

Accessories (Order Separately)

(2110)

250

263

1510

LED (SD)

LED (PWR)

LED (RD)

USB connector

(type A plug)

Serial connector

USB-Serial Conversion Cable

E58-CIFQ2

Connected to the E58-CIFQ2 USB-Serial Conversion Cable

Conversion Cable

(1,510)

250

(2,110)

E58-CIFQ2 (Order separately)

Conversion Cable

263

1,510

Conversion Cable

E58-CIFQ2-E

Note: Always use this product together with the E58-CIFQ2.

3.8

Terminal Covers (Cannot be used on a Push-In Plus terminal block type)

E53-COV24 (Three Covers provided.)

The Terminal Covers are provided with the Digital Temperature Controller.

Order the Terminal Cover separately if it becomes lost or damaged.

Waterproof Packing

Y92S-P9 (for DIN 48

× 96)

The Waterproof Packing is provided with the Digital Temperature Controller.

Order the Waterproof Packing separately if it becomes lost or damaged. The

Waterproof Packing can be used to achieve an IP66 degree of protection. Also,

keep the Port Cover on the front-panel Setup Tool port of the E5ED/E5ED-B

securely closed.

(Deterioration, shrinking, or hardening of the waterproof packing may occur

depending on the operating environment. Therefore, periodic replacement is

recommended to ensure the level of waterproofing specified in IP66. The time for

periodic replacement depends on the operating environment. Be sure to confirm

this point at your site. Consider three years as a rough standard.)

Setup Tool Port Cover for front panel

Y92S-P7

Order this Port Cover separately if the

Port Cover on the front-panel Setup Tool

port is lost or damaged. The Waterproof

Packing must be periodically replaced

because it may deteriorate, shrink, or

harden depending on the operating

environment.

Mounting Adapter

Y92F-51 (Two Adapters provided.)

One pair is provided with the Controller.

Order this Adapter separately if it

becomes lost or damaged.
