E3S-A

Note: Models numbers for Through-beam Sensors (E3S-AT

@6) are for sets that include both the Emitter and Receiver.

The model number of the Emitter is expressed by adding "-L" to the set model number (example: E3S-AT16-L), the model number of the Receiver, by adding "-D"

(example: E3S-AT16-D). Refer to Ordering Information to confirm model numbers for Emitter and Receivers.

Sensors with Standard Connectors

29.2

5.5

1.2 10.7

3.1

7.2

5

7.2

16.9

28.9

20

35.5

10.5

Stainless

steel

(SUS304)

*The Mounting Bracket can be attached to side A.

Optical axis

Optical

axis

A*

Two, M3

× 12 screws

With Mounting Bracket Attached

E3S-AT16/36 (Receiver)

1.3

10.5

20

8

21

40

12.9

7

(10)

12

12.4

20

Lens (7

× 7)

Optical axis

Two, M3 × 12 screws

Sensitivity adjuster (white)

Light indicator

(red)

Stability indicator (green)

Operation mode

selector switch

Two, M3

M12 Connector

Mounting Holes

29.2

5.5

1.2 10.7

3.1

7.2

5

20

35.5

10.5

7.2

16.9

28.9

Stainless

steel

(SUS304)

*The Mounting Bracket can be attached to side A.

Optical axis

Optical

axis

A*

Two, M3

× 12 screws

With Mounting Bracket Attached

E3S-AT16/36 (Emitter)

40

17.8

(10)

12

12.4

1.3

10.5

20

8

21

20

Two, M3

× 12 screws

Lens (7

× 7)

Optical axis

Power indicator (red)

Two, M3

M12 Connector

Mounting Holes
