LH R974
DATASHEET
DATASHEET
11 | Version 1.3 | 2022-10-14
Electrical Internal Circuit
Recommended Solder Pad 9)
1.2 (0.047)
0.9 (0.035)
OHAPY607
1.2 (0.047)
For superior solder joint connectivity results we recommend soldering under standard nitrogen atmosphere. Package not
suitable for ultra sonic cleaning.
