ADG774A
Data Sheet
Rev. C | Page 10 of 14
0.1µF
5V
VS
IN
SD
VDD
GND
RL
100Ω
CL
35pF
VOUT
EN
3V
50%
50%
90%
90%
VIN
VOUT
tON
tOFF
Figure 22. Switching Times
0.1µF
5V
VS
EN
S1A
D1
VDD
GND
RL
100Ω
CL
35pF
VOUT
S1B
DECODER
VS
80%
80%
VIN
VOUT
tD
tD
50%
50%
3V
0V
VS
Figure 23. Break-Before-Make Time Delay
5V
EN
S1A
VDD
CL
1nF
S1B
VIN
VOUT
3V
QINJ = CL × ∆VOUT
∆VOUT
CL
1nF
CL
1nF
CL
1nF
D1 VOUT
D2 VOUT
D3 VOUT
D4 VOUT
ADG774A
1 OF 2
DECODER
IN
S2A
S2B
S3A
S3B
S4A
S4B
VS
RS
Figure 24. Charge Injection
