ERRATA SHEET
101/102
20.7 I/O PORT INPUT HIGH LEVEL (VIH)
The VIH min value is 0.8*VDD and not 0.7*VDD as specified for the final silicon.
21 DEVICE MARKING
Figure 51. Revision Marking on Box Label and Device Marking
22 ERRATA SHEET REVISION HISTORY
Revision
Main Changes
Date
1.2
Updated Section 20.5 "SUPPLY CURRENT IN HALT MODE (SUSPEND) Limi-
tations" on page 100
Added Section 20.6 "Start-UP" on page 100
03/13/03
TYPE xxxx
Internalxxx$xx
Trace Code
LAST 2 DIGITS AFTER $
IN INTERNAL SALES TYPE
INDICATE SILICON REV.
LAST LETTER OF TRACE CODE
ON DEVICE INDICATES
SILICON REV.
ON BOX LABEL
