Preliminary Technical Data
AD8363
Rev. PrB | Page 3 of 14
Parameter
Conditions
Min
Typ
Max
Unit
12 dB peak-to-rms ratio (WiMAX), over 40 dB dynamic range
±0.1
dB
14.0 dB peak-to-rms ratio (16C CDMA2K), over 40 dB dynamic range
±0.1
dB
256 QAM CF=8
±0.1
dB
Input Impedance
Single-ended drive
50/TBD
Ω/pF
2140 MHz
TCM1=0.49V, TCM2=1.2V
Output Voltage: High Power in
PIN = -10 dBm
2.31
V
Output Voltage: Low Power in
PIN = -40 dBm
0.72
V
±1.0 dB Dynamic Range
CW input, TA = +25°C
40
dB
Maximum Input Level, ±1.0 dB
-10
Minimum Input Level, ±1.0 dB
-50
Deviation vs. Temperature
Deviation from output at 25°C
-40°C < TA < +85°C; PIN = -10 dBm
±0.6
dB
-40°C < TA < +85°C; PIN = -40 dBm
±0.5
dB
Logarithmic Slope
52.5
mV/dB
Logarithmic Intercept
-53.5
dBm
Deviation from CW Response
13 dB peak-to-rms ratio (WCDMA), over 40 dB dynamic range
±0.1
dB
12 dB peak-to-rms ratio (WiMAX), over 40 dB dynamic range
±0.1
dB
14.0 dB peak-to-rms ratio (16C CDMA2K), over 40 dB dynamic range
±0.1
dB
256 QAM CF=8
±0.1
dB
Input Impedance
Single-ended drive
50/TBD
Ω/pF
2600 MHz
TCM1=, TCM2=
Output Voltage: High Power in
PIN = -10 dBm
2.15
V
Output Voltage: Low Power in
PIN = -40 dBm
0.52
V
±1.0 dB Dynamic Range
CW input, TA = +25°C,
35
dB
Maximum Input Level, ±1.0 dB
-12
Minimum Input Level, ±1.0 dB
-40
Deviation vs. Temperature
Deviation from output at 25°C
-40°C < TA < +85°C; PIN = -10 dBm
TBD
dB
-40°C < TA < +85°C; PIN = -40 dBm
TBD
dB
Logarithmic Slope
53.2
mV/dB
Logarithmic Intercept
-49.9
dBm
Deviation from CW Response
13 dB peak-to-rms ratio (WCDMA), over 40 dB dynamic range
±0.1
dB
12 dB peak-to-rms ratio (WiMAX), over 40 dB dynamic range
±0.1
dB
14.0 dB peak-to-rms ratio (16C CDMA2K), over 40 dB dynamic range
±0.1
dB
256 QAM CF=8
±0.1
dB
Input Impedance
Single-ended drive
50/TBD
Ω/pF
3.8 GHz
TCM1=0.56V, TCM2=1.0V
Output Voltage: High Power in
PIN = -15 dBm
2.0
V
Output Voltage: Low Power in
PIN = -40 dBm
0.5
V
±1.0 dB Dynamic Range
CW input, TA = +25°C,
33
dB
Maximum Input Level, ±1.0 dB
-16
Minimum Input Level, ±1.0 dB
-49
Deviation vs. Temperature
Deviation from output at 25°C
-40°C < TA < +85°C; PIN = -10 dBm
+/- 1.0
dB
-40°C < TA < +85°C; PIN = -40 dBm
+/- 0.8
dB
Logarithmic Slope
54.7
mV/dB
Logarithmic Intercept
-50
dBm
Deviation from CW Response
13 dB peak-to-rms ratio (WCDMA), over 40 dB dynamic range
±0.1
dB
12 dB peak-to-rms ratio (WiMAX), over 40 dB dynamic range
±0.1
dB
14.0 dB peak-to-rms ratio (16C CDMA2K), over 40 dB dynamic range
±0.1
dB
256 QAM CF=8
±0.1
dB
5.8 GHz
TCM1=0.88V, TCM2= 1.0V
Output Voltage: High Power in
PIN = -20 dBm
1.5
V
Output Voltage: Low Power in
PIN = -40 dBm
0.35
V
±1.0 dB Dynamic Range
CW input, TA = +25°C
30
dB
