ADA4505-2
Rev. 0 | Page 13 of 20
TA = 25°C, unless otherwise noted.
1.8
1.5
1.2
0.9
0.6
0.3
0
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = 1.8V
VIN = 1.7V
G = 1
RL = 100kΩ
Figure 44. Output Swing vs. Frequency
10
1
0.1
0.01
0.001
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = 1.8V
VIN = 100mV p-p
RL = 100kΩ
G = –1
G = +1
Figure 45. THD + Noise vs. Frequency
6
5
4
3
2
1
0
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = 5V
VIN = 4.9V
G = 1
RL = 100kΩ
Figure 46. Output Swing vs. Frequency
10
1
0.1
0.01
0.001
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = 5V
VIN = 100mV p-p
RL = 100kΩ
G = –1
G = +1
Figure 47. THD + Noise vs. Frequency
