TYPICAL PERFORMANCE CHARACTERISTICS

20

10

0

–10

–20

–30

–40

–50

250

500

750

1000

1250

1500

1750

2000

2250

FREQUENCY (MHz)

0dB

31dB

Figure 3. Gain vs. Frequency by Gain Code,

All Input Attenuator (ATTN 1) Code Steps

20

10

0

–10

–20

–30

–40

–50

250

500

750

1000

1250

1500

1750

2000

2250

FREQUENCY (MHz)

0dB

31dB

Figure 4. Gain vs. Frequency by Gain Code,

All Output Attenuator (ATTN 2) Code Steps

0

–5

–10

–15

–20

–25

–30

–35

–40

–45

–50

250

500

750

1000

1250

1500

1750

2000

2250

FREQUENCY (MHz)

RFIN 0dB ATTENUATION

RFIN 31dB ATTENUATION

RFOUT 0dB ATTENUATION

RFOUT 31dB ATTENUATION

LOOP OUT

Figure 5. Return Loss vs. Frequency, RFIN, RFOUT, and LOOP OUT

40

35

30

25

20

250

500

750

1000

1250

1500

1750

2000

2250

FREQUENCY (MHz)

–40°C

–25°C

0°C

+25°C

+85°C

Figure 6. Output Third-Order Intercept vs. Frequency Across Temperature,

Maximum Gain, 0 dBm per Input Tones with 1 MHz Spacing

30

25

20

15

10

250

500

750

1000

1250

1500

1750

2000

2250

FREQUENCY (MHz)

–40°C

–25°C

0°C

+25°C

+85°C

Figure 7. Output P1dB Compression vs. Frequency Across Temperature,

Maximum Gain

10

8

6

4

2

0

20

16

12

8

4

0

250

500

750

1000

1250

1500

1750

2000

2250

FREQUENCY (MHz)

GAIN

NOISE FIGURE

Figure 8. Noise Figure and Gain vs. Frequency,

at Maximum Gain
