74LVC08A

5/11

Figure 3: Test Circuit

RT = ZOUT of pulse generator (typically 50Ω)

Table 10: Test Circuit And Waveform Symbol Value

Figure 4: Waveform: Propagation Delay (f=1MHz; 50% duty cycle)

Symbol

VCC

1.65 to 1.95V

2.3 to 2.7V

2.7V

3.0 to 3.6V

30pF

50pF

1000

Ω

500

Ω

500

Ω

500

Ω

VIH

VCC

2.7V

VCC/2

1.5V

VOH

VCC

3.0V

tr = tr

<2.0ns

<2.5ns
