74LVC374A

3/14

Table 4: Absolute Maximum Ratings

Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these conditions is

not implied

Table 5: Recommended Operating Conditions

1) Truth Table guaranteed: 1.2V to 3.6V

Symbol

Parameter

Value

Unit

Supply Voltage

-0.5 to +7.0

V

DC Input Voltage

-0.5 to +7.0

V

-0.5 to +7.0

V

DC Output Voltage (High or Low State) (note 1)

V

DC Input Diode Current

- 50

mA

DC Output Diode Current (note 2)

- 50

mA

DC Output Current

± 50

mA

± 100

mA

Storage Temperature

-65 to +150

°C

Lead Temperature (10 sec)

300

°C

Symbol

Parameter

Value

Unit

Supply Voltage (note 1)

1.65 to 3.6

V

Input Voltage

0 to 5.5

V

0 to 5.5

V

Output Voltage (High or Low State)

V

± 24

mA

± 12

mA

± 8mA

± 4mA

Operating Temperature

-55 to 125

°C

dt/dv

Input Rise and Fall Time (note 2)

0 to 10

ns/V
