571 / 1158 page  Section 10 16-Bit Timer Pulse Unit (TPU) Rev.1.00 Jun. 07, 2006 Page 519 of 1102 REJ09B0294-0100 Table 10.20 TIOR_5 Description Bit 7 IOB3 Bit 6 IOB2 Bit 5 IOB1 Bit 4 IOB0 TGRB_5 Function TIOCB5 Pin Function 0 0 0 0 Output disabled 0 0 0 1 Initial output is 0 output 0 output at compare match 0 0 1 0 Initial output is 0 output 1 output at compare match 0 0 1 1 Initial output is 0 output Toggle output at compare match 0 1 0 0 Output disabled 0 1 0 1 Initial output is 1 output 0 output at compare match 0 1 1 0 Initial output is 1 output 1 output at compare match 0 1 1 1 Output compare register Initial output is 1 output Toggle output at compare match 1 x 0 0 Capture input source is TIOCB5 pin Input capture at rising edge 1 x 0 1 Capture input source is TIOCB5 pin Input capture at falling edge 1 x 1 x Input capture register Capture input source is TIOCB5 pin Input capture at both edges [Legend] X: Don't care |
|
