607 / 1158 page  Section 10 16-Bit Timer Pulse Unit (TPU) Rev.1.00 Jun. 07, 2006 Page 555 of 1102 REJ09B0294-0100 Figure 10.23 shows examples of PWM waveform output with 0% duty cycle and 100% duty cycle in PWM mode. TCNT value TGRA H'0000 TIOCA Time TGRB 0% duty TGRB changed TGRB changed TGRB changed TCNT value TGRA H'0000 TIOCA Time TGRB 100% duty TGRB changed TGRB changed TGRB changed Output does not change when compare matches in cycle register and duty register occur simultaneously TCNT value TGRA H'0000 TIOCA Time TGRB 100% duty TGRB changed TGRB changed TGRB changed Output does not change when compare matches in cycle register and duty register occur simultaneously 0% duty Figure 10.23 Example of PWM Mode Operation (3) |
|
