background image
Section 15 Serial Communication Interface (SCI, IrDA, CRC)
Rev.1.00 Jun. 07, 2006 Page 692 of 1102
REJ09B0294-0100
Bit
Bit Name
Initial
Value
R/W
Description
3
2
1
0
ACS3
ACS2
ACS1
ACS0
0
0
0
0
R/W
R/W
R/W
R/W
1000: 115.132 kbps of average transfer rate specific to
P
φ = 24 MHz is selected (operated using the base
clock with a frequency 16 times the transfer rate)
1001: 460.526 kbps of average transfer rate specific to
P
φ = 24 or MHz or 230.263 kbps of average
transfer rate specific to P
φ = 12MHz is selected
(operated using the base clock with a frequency
16 times the transfer rate)
1010: 720 kbps of average transfer rate specific to P
φ =
24 MHz is selected (operated using the base clock
with a frequency 8 times the transfer rate)
1011: 921.053 kbps of average transfer rate specific to
P
φ = 24 or MHz or 460.526 kbps of average
transfer rate specific to P
φ = 12MHz is selected
(operated using the base clock with a frequency 8
times the transfer rate)
1100: 720 kbps of average transfer rate specific to P
φ =
32 MHz is selected (operated using the base clock
with a frequency 16 times the transfer rate)
1101: Reserved (setting prohibited)
111x: Reserved (setting prohibited)
