Section 18 A/D Converter
Rev.1.00 Jun. 07, 2006 Page 850 of 1102
REJ09B0294-0100
Module data bus
Control circuit
Internal
data bus
10-bit A/D
Comparator
+
–
Sample-and-
hold circuit
ADI0 interrupt
signal
AVCC
Vref
AVSS
AN0
AN1
AN2
AN3
AN4
AN5
AN6
AN7
ADTRG0
Conversion start
trigger from the
TPU or TMR
[Legend]
ADCR:
A/D control register
ADCSR: A/D control/status register
ADDRA: A/D data register A
ADDRB: A/D data register B
ADDRC: A/D data register C
ADDRD: A/D data register D
ADDRE: A/D data register E
ADDRF: A/D data register F
ADDRG: A/D data register G
ADDRH: A/D data register H
Figure 18.1 Block Diagram of A/D Converter
