PACKAGE MECHANICAL DATA

SIP3 Plastic

Package

Types

Marking

SIP3

THBT200S

THBT200S

MARKING :

REF.

DIMENSIONS

Millimetres

Inches

Min.

Typ. Max.

Min.

Typ.

Max.

A

7.10

0.280

a1

2.80

0.110

a2

1.50

1.90 0.059

0.075

B

10.15

0.400

b1

0.50

0.020

b2

1.35

1.75 0.053

0.069

c1

0.38

0.50 0.015

0.020

e

2.54

0.100

e3

7.62

0.200

I

10.50

0.413

L

3.30

0.130

Z

1.50

0.059

ORDER CODE

THBT

200

S

BREAKDOWN VOLTAGE

PACKAGE :

S = SIP3

BIDIRECTIONAL TRISIL

Packaging: Products supplied in antistatic tubes.

Weight: 0.55g

®
