ABSOLUTE MAXIMUM RATINGS

THERMAL RESISTANCE

Table 4.

Parameter

Rating

Supply Voltage

±18 V

Input Voltage

Differential Input Voltage1

±1 V

Output Short-Circuit to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Lead Temperature Range (Soldering 60 sec)

300°C

Junction Temperature

150°C

its exposed paddle soldered to a pad (if applicable) on a 4-layer

JEDEC standard PCB with zero air flow.

Table 5.

Package Type

Unit

8-Lead LFCSP_VD (CP-8-2)

78

20

°C/W

8-Lead SOIC (R-8) (AD8597)

140

39

°C/W

8-Lead SOIC (R-8) (AD8599)

120

36

°C/W

POWER SEQUENCING

to 5 mA.

The op amp supplies should be applied simultaneously. The

op amp supplies should be stable before any input signals are

applied. In any case, the input current must be limited to 5 mA.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
