ADA4858-3

Rev. 0 | Page 15 of 16

PD (POWER-DOWN) PIN

The ADA4858-3 is equipped with a PD (power-down) pin for

all three amplifiers. This allows the user the ability to reduce the

quiescent supply current when an amplifier is not active. The

power-down threshold levels are derived from ground level.

The amplifiers are powered down when the voltage applied to

the PD pin is greater than a certain voltage from ground. In a

5 V supply application, the voltage is greater than 2 V, and in a

3.3 V supply application, the voltage is greater than 1.5 V. The

amplifier is enabled whenever the PD pin is left floating (not

connected). If the PD pin is not used, it is best to leave it floating

or connected to ground. Note that the power-down feature does

not control the charge pump output voltage and current.

Table 6. Power-Down Voltage Control

PD Pin

5 V

3.3 V

Not

Active

<1.5 V

<1 V

Active

>2 V

>1.5 V

POWER SUPPLY BYPASSING

Careful attention must be paid to bypassing the power supply

pins of the ADA4858-3. High quality capacitors with low

equivalent series resistance (ESR), such as multilayer ceramic

capacitors (MLCCs), should be used to minimize supply voltage

ripple and power dissipation. A large, usually tantalum,

capacitor between 2.2 μF to 47 μF located in proximity to the

ADA4858-3 is required to provide good decoupling for lower

frequency signals. The actual value is determined by the circuit

transient and frequency requirements. In addition, 0.1 μF MLCC

decoupling capacitors should be located as close to each of the

power supply pins and across from both supplies as is physically

possible, no more than 1/8-inch away. The ground returns

should terminate immediately into the ground plane. Locating

the bypass capacitor return close to the load return minimizes

ground loops and improves performance.

LAYOUT

As is the case with all high speed applications, careful attention

to printed circuit board (PCB) layout details prevents associated

board parasitics from becoming problematic. The ADA4858-3

can operate at up to 600 MHz; therefore, proper RF design

techniques must be employed. The PCB should have a ground

plane covering all unused portions of the component side of the

board to provide a low impedance return path. Removing the

ground plane on all layers from the area near and under the

input and output pins reduces stray capacitance. Signal lines

connecting the feedback and gain resistors should be kept as

short as possible to minimize the inductance and stray

capacitance associated with these traces. Termination resistors

and loads should be located as close as possible to their respective

inputs and outputs. Input and output traces should be kept as

far apart as possible to minimize coupling (crosstalk) through

the board. Adherence to microstrip or stripline design techniques

for long signal traces (greater than 1 inch) is recommended. For

more information on high speed board layout, see “A Practical

Guide to High-Speed Printed-Circuit-Board Layout”, Analog

Dialogue, Volume 39, Number 3, September 2005 at

www.analog.com.
